LCP Series Batteries use the most advanced technology of fast punched thin plate (FPTP) for punching grid batteries. Compared with traditional technologies, FPTP technology is faster, simpler, more energy efficient, more environmentally friendly, also higher product consistency. This technology enables mechanized and automated production, reducing lead consumption by 30% and saving 40% of energy.
Contact US| Model | Rated Voltage | W15min | 20hr | 10hr | Length | Width | Height | TH | Weight | Terminal Type |
| V | 1.67V/cell | 1.75V/cell | 1.80V/cell | mm | mm | mm | mm | kg | ||
| LCP6-22W | 6 | 22 | 7 | 150 | 34 | 94 | 100 | 1 | T1/T2 | |
| LCP6-24W | 6 | 24 | 7 | 150 | 34 | 94 | 100 | 1.07 | T1/T2 | |
| LCP12-19W | 12 | 19 | 5.5 | 151 | 51 | 93 | 99 | 1.75 | T1/T2 | |
| LCP12-22W | 12 | 22 | 7 | 151 | 65 | 93.5 | 99.5 | 1.82 | T1/T2 | |
| LCP12-24W | 12 | 24 | 7 | 151 | 65 | 93.5 | 99.5 | 2.13 | T1/T2 | |
| LCP12-26W | 12 | 26 | 7 | 151 | 65 | 93.5 | 99.5 | 2.17 | T1/T2 | |
| LCP12-28W | 12 | 28 | 7.5 | 151 | 65 | 93.5 | 99.5 | 2.24 | T1/T2 | |
| LCP12-32W | 12 | 32 | 8 | 151 | 65 | 93.5 | 99.5 | 2.31 | T1/T2 | |
| LCP12-34W | 12 | 34 | 8 | 151 | 65 | 93.5 | 99.5 | 2.35 | T1/T2 | |
| LCP12-36W | 12 | 36 | 9 | 151 | 65 | 93.5 | 99.5 | 2.46 | T1/T2 | |
| LCP12-40W | 12 | 40 | 12 | 151 | 98 | 95 | 101 | 3.38 | T1/T2 | |
| LCP12-42W | 12 | 42 | 12 | 151 | 98 | 95 | 101 | 3.48 | T1/T2 | |
| LCP12-50W | 12 | 50 | 14 | 151 | 98 | 95 | 101 | 3.58 | T1/T2 |
Parameter information subject to the contract, here for your reference only.
? 5years design life (25℃)
? Lead calcium alloy, sealed design, no watering required
? Puncture resistant micro-porous glass mat separators extend life
?Automatic grid punch manufacturing process and unique technology optimizes power capacity,cell consistency,and long-term reliability and service life
1.Uninterruptable Power Supply (UPS)
2.Electric Power System (EPS)
3.Emergency backup power supply
4.Alarm and security system
5.Communication power supply
6.DC power supply
7.Auto control system
